Hengshui Thompson Hose Technologies Co., Ltd.
| Place of Origin: | China |
|---|---|
| Brand Name: | thompson |
| Model Number: | HOG2B |
| Minimum Order Quantity: | 1000Meter |
| Price: | negotiable |
| Packaging Details: | wrapped with yellow/white woven belt or plastic firm |
| Delivery Time: | 20-30 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200,000 meter per month |
| Material: | Synthetic Rubber,Rubber+Steel Wire | Color: | Black Or Other |
|---|---|---|---|
| Size: | 1/4"~2" | Cover: | Weather Resistant Synthetic Rubber |
| Application: | Industrial,suitable To Carry Hydraulic Fluids,used For Hydraulic Oil Delivery,high ImPUlse Hydraulic Applications. | Length: | 20m 40m 50m 100m |
| Name: | EN 853 2SN Sae 100 R2at 3/8 Inch Wire Braid Hydraulic Hose | Working Temperature: | -40~+120 |
| Oem Service: | Accept,Yes | Item: | Hydraulic Hose R2 2SN |
| High Light: | sae 100 r2 at braided hydraulic hose,2" braided hydraulic hose 4000 psi,sae 100 r2 at wire braided hose |
||
| EN853 2SN/SAE100 R2AT | ||||||||||||
| MAIN APPLICATION: | Medium-high pressure lines,including construction, machine tool and agricultural application,using petroleum or water-based hydraulic fluids. | |||||||||||
| APPLICABLE SPECS: | EN 853 2SN - SAE 100 R2AT - ISO 1436-1 2SN | |||||||||||
| TEMPERATURE RANGE: | -40°F / +212°F -40°C / +100°C | |||||||||||
| INNER TUBE: | Oil resistant synthetic rubber | |||||||||||
| REINFORCEMENT: | Two high tensile steel braids | |||||||||||
| COVER: | Synthetic rubber with high abrasion, ozone and weather resistance, Fire resistant with MSHA approval (rubber color and surface finish can be customized as per customer's request) | |||||||||||
| DN | Hose I.D | Wire O.D | Hose O.D | Working Pressure | Burst Pressure | Minimum Bend Radius | Weight | Length | |||
| inch | mm | mm | mm | MPa | psi | MPa | psi | mm | kg/m | metres | |
| 5 | 3/16 | 4.8 | 11.1 | 13.4 | 41.4 | 6000 | 165 | 23720 | 89 | 0.32 | 50/100 |
| 6 | 1/4 | 6.4 | 12.7 | 15.0 | 40.0 | 5800 | 160 | 22840 | 102 | 0.36 | 50/100 |
| 8 | 5/16 | 7.9 | 14.3 | 16.6 | 36.0 | 5250 | 140 | 20000 | 114 | 0.45 | 50/100 |
| 10 | 3/8 | 9.5 | 16.7 | 19.0 | 33.1 | 4800 | 132 | 18840 | 127 | 0.54 | 50/100 |
| 13 | 1/2 | 12.7 | 19.8 | 22.2 | 27.6 | 4000 | 110 | 15720 | 178 | 0.68 | 50/100 |
| 16 | 5/8 | 15.9 | 23 | 25.4 | 25.0 | 3630 | 100 | 14280 | 203 | 0.8 | 50/100 |
| 19 | 3/4 | 19.0 | 27 | 29.3 | 21.5 | 3120 | 85 | 12280 | 241 | 0.94 | 50/100 |
| 25 | 1 | 25.4 | 34.9 | 38.0 | 16.5 | 2400 | 65 | 9420 | 305 | 1.35 | 50 |
| 32 | 1 1/4 | 31.8 | 44.5 | 48.3 | 12.5 | 1820 | 50 | 7140 | 419 | 2.15 | 20/40 |
| 38 | 1 1/2 | 38.1 | 50.8 | 54.6 | 9.0 | 1310 | 36 | 5140 | 508 | 2.65 | 20/40 |
| 51 | 2 | 50.8 | 63.5 | 67.3 | 8.0 | 1160 | 32 | 4560 | 635 | 3.42 | 20/40 |
Featured Description
Structure of 2hydraulic hose manufacturers EN853 1SN 2SN /SAE 100 R1 R2 Wire Braided hydraulic hose
High pressure hydraulic hose Consists of inner tube, middle layer, two wire reinforcements and cover. Inner tube is to transmit liquid under pressure and protect wire against corrosion while cover is to protect wire against abrasion, wire layer is the structure materials that providing reinforcement.
Application
High pressure hydraulic hose Mainly used in mine hydraulic support, oil exploration, suitable to engineer construction, crane transport, forging metallurgy, mining equipment, ships, injection molding machinery, agricultural machinery various machine tools.
company information
the main product is including all kinds of wire braid hydraulic hose etc. in order to supply the best exporting service for the customer, our own factory and trading company, so that we can supply the good quality product and competitive price and attentive service for the customer. now the rubber wire braid hydraulic hose products have been exported to south asia, the middle east, europe, and africa.
