Place of Origin: | China |
---|---|
Brand Name: | thompson |
Model Number: | HOG2B |
Minimum Order Quantity: | 1000Meter |
Price: | negotiable |
Packaging Details: | wrapped with yellow/white woven belt or plastic firm |
Delivery Time: | 20-30 days |
Payment Terms: | L/C, T/T |
Supply Ability: | 200,000 meter per month |
Material: | Synthetic Rubber,Rubber+Steel Wire | Color: | Black Or Other |
---|---|---|---|
Size: | 1/4"~2" | Cover: | Weather Resistant Synthetic Rubber |
Application: | Industrial,suitable To Carry Hydraulic Fluids,used For Hydraulic Oil Delivery,high ImPUlse Hydraulic Applications. | Length: | 20m 40m 50m 100m |
Type: | Hydraulic Hose | Working Temperature: | -40~+120 |
Oem Service: | Accept,Yes | Item: | Hydraulic Hose R2 2SN |
High Light: | 4.8mm wire braided rubber hose,high pressure wire braided rubber hose,mine hydraulic support wire braided hose |
3/8" En 853 2sn / Sae 100 R2at Wire Braid Hydraulic Rubber Hose Wp 330 Bar
Steel Wire Braid Hydraulic Hose: SAE 100 R2AT/DIN EN 853 2SN
Tube: Oil resistant synthetic rubber
Reinforcement: Two high tensile steel wire braid
Cover: Abrasion and weather resistant synthetic rubber
Temperature range : -40 ℃ to +100 ℃
Applicable standards: EN 853 2SN/SAE 100 R2AT
DN | Hose I.D | Wire O.D | Hose O.D | Working Pressure | Burst Pressure | Minimum Bend Radius | Weight | Length | |||
inch | mm | mm | mm | MPa | psi | MPa | psi | mm | kg/m | metres | |
5 | 3/16 | 4.8 | 11.1 | 13.4 | 41.4 | 6000 | 165 | 23720 | 89 | 0.32 | 50/100 |
6 | 1/4 | 6.4 | 12.7 | 15.0 | 40.0 | 5800 | 160 | 22840 | 102 | 0.36 | 50/100 |
8 | 5/16 | 7.9 | 14.3 | 16.6 | 36.0 | 5250 | 140 | 20000 | 114 | 0.45 | 50/100 |
10 | 3/8 | 9.5 | 16.7 | 19.0 | 33.1 | 4800 | 132 | 18840 | 127 | 0.54 | 50/100 |
13 | 1/2 | 12.7 | 19.8 | 22.2 | 27.6 | 4000 | 110 | 15720 | 178 | 0.68 | 50/100 |
16 | 5/8 | 15.9 | 23 | 25.4 | 25.0 | 3630 | 100 | 14280 | 203 | 0.8 | 50/100 |
19 | 3/4 | 19.0 | 27 | 29.3 | 21.5 | 3120 | 85 | 12280 | 241 | 0.94 | 50/100 |
25 | 1 | 25.4 | 34.9 | 38.0 | 16.5 | 2400 | 65 | 9420 | 305 | 1.35 | 50 |
32 | 1 1/4 | 31.8 | 44.5 | 48.3 | 12.5 | 1820 | 50 | 7140 | 419 | 2.15 | 20/40 |
38 | 1 1/2 | 38.1 | 50.8 | 54.6 | 9.0 | 1310 | 36 | 5140 | 508 | 2.65 | 20/40 |
51 | 2 | 50.8 | 63.5 | 67.3 | 8.0 | 1160 | 32 | 4560 | 635 | 3.42 | 20/40 |
Featured Description
Structure of 2hydraulic hose manufacturers EN853 1SN 2SN /SAE 100 R1 R2 Wire Braided hydraulic hose
High pressure hydraulic hose Consists of inner tube, middle layer, two wire reinforcements and cover. Inner tube is to transmit liquid under pressure and protect wire against corrosion while cover is to protect wire against abrasion, wire layer is the structure materials that providing reinforcement.
Application
High pressure hydraulic hose Mainly used in mine hydraulic support, oil exploration, suitable to engineer construction, crane transport, forging metallurgy, mining equipment, ships, injection molding machinery, agricultural machinery various machine tools.
company information
the main product is including all kinds of wire braid hydraulic hose etc. in order to supply the best exporting service for the customer, our own factory and trading company, so that we can supply the good quality product and competitive price and attentive service for the customer. now the rubber wire braid hydraulic hose products have been exported to south asia, the middle east, europe, and africa.
FAQ:
Q1. What is your terms of packing for Stainless Steel Braided Rubber Hose?
A: Generally, we pack our goods plastic bags and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: If mass production order T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. How about your delivery time?
A: Generally, it will take 3 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q4. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q5. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
