Chenbo Rubber and Plastic Technology (Hebei) Co., Ltd
| Brand Name: | Yeli |
|---|---|
| Model Number: | HOG4SP |
| Minimum Order Quantity: | 360Meter |
| Price: | negotiable |
| Packaging Details: | wrapped with yellow/white woven belt or plastic firm |
| Delivery Time: | 15-20 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200,000 meter per month |
| Reinforcement: | Four Layers Of Alternating Direction Steel Wire Spiral | Material: | Synthetic Rubber |
|---|---|---|---|
| Color: | Black | Size: | 6mm To 51mm |
| Cover: | Weather Resistant Synthetic Rubber | Product Name: | 4 Steel Wire Spiral Sae 100 R9 Specifications Hydraulic Hose,6mm Diameter 4 Layer Wire Spiral Hydraulic Hose With Steel Wire Sprial,4 Wire Spiral 4SP Hydraulic Hose,Hydraulic Hose High Press Multispiral Hose 4sp |
| Application: | Industrial | Type: | DIN EN854 |
| Surface: | Black Wrapped | Working Pressure: | 16.5 To 45Mpa |
| Business Type: | Manufacturer,Factory | Feature: | Spiral,abrasion And Weather Resistant |
| Working Temperature: | -40℃ To +100℃ Or -40℉ To +212℉ | Oem Service: | Accept,Yes |
| Highlight: | Wire Spiral Hydraulic Hose 4SP,Wire Spiral Hydraulic Hose 4SH,construction 4sh hose |
||
Multispiral Hydraulic Hose
Inner Tube: Oil resistant synthetic rubber
Reinforcement: Four or six spirals of high tensile steel wire
Cover: Abrasion and weather resistant synthetic rubber
Temperature Range:-40℃ to +100℃
Application: Applications include construction, mining, farming, and high performance industrial equipment.
|
EN 856 4SP Multispiral Hydraulic hose
|
|||||||||
|
Hose ID
|
Wire OD
|
Hose OD
|
work pressure
|
Burst pressure
|
Min. Bend Radius
|
Weight
|
|||
|
Inch
|
mm
|
mm
|
mm
|
MPa
|
Psi
|
MPa
|
Psi
|
mm
|
kg/m
|
|
3/8"
|
9.5
|
17.5
|
21.4
|
44.5
|
6450
|
180
|
26000
|
180
|
0.78
|
|
1/2"
|
12.7
|
20.2
|
24.0
|
41.5
|
6000
|
166
|
24000
|
230
|
0.89
|
|
5/8"
|
15.9
|
23.8
|
28.2
|
35.0
|
5000
|
140
|
20000
|
250
|
1.11
|
|
3/4"
|
19.0
|
28.2
|
32.2
|
35.0
|
5000
|
140
|
20000
|
300
|
1.59
|
|
1"
|
25.4
|
35.5
|
39.7
|
28.0
|
4000
|
112
|
16000
|
340
|
2.02
|
|
1-1/4"
|
31.8
|
46.0
|
50.8
|
21.0
|
3000
|
84
|
12000
|
460
|
2.32
|
|
1-1/2"
|
38.1
|
52.4
|
57.7
|
18.5
|
2700
|
74
|
10800
|
560
|
3.7
|
|
2"
|
50.8
|
65.3
|
69.6
|
16.5
|
2400
|
66
|
9600
|
660
|
5.47
|
Multispiral Hydraulic Hose EN 856 4SH
Inner Tube: Oil resistant synthetic rubber
Reinforcement: Four spirals of high tensile steel wire
Cover: Abrasion and weather resistant synthetic rubber
Temperature Range:-40℃ to +100℃
Application: Applications include construction, mining, farming, and high performance industrial equipment.
|
EN 856 4SH Multispiral Hydraulic hose
|
|||||||||
|
Hose ID
|
Wire OD
|
Hose OD
|
work pressure
|
Burst pressure
|
Min. Bend Radius
|
Weight
|
|||
|
Inch
|
mm
|
mm
|
mm
|
MPa
|
Psi
|
MPa
|
Psi
|
mm
|
kg/m
|
|
3/4"
|
19.0
|
28.4
|
32.0
|
42.0
|
6000
|
168
|
24000
|
280
|
1.61
|
|
1"
|
25.4
|
35.2
|
38.6
|
38.0
|
5500
|
152
|
22000
|
340
|
2.00
|
|
1-1/4"
|
31.8
|
41.9
|
45.8
|
32.5
|
4700
|
130
|
18800
|
460
|
2.46
|
|
1-1/2"
|
38.1
|
48.8
|
53.3
|
29.0
|
4200
|
116
|
16800
|
560
|
3.35
|
|
2"
|
50.8
|
63.2
|
68.1
|
25.0
|
3600
|
100
|
14400
|
700
|
4.98
|
